DSPPA MP210U - Specifications; Technical Specifications Overview

DSPPA MIXING AMPLIFIER
- 9 -
SPECIFICATIONS
1
2
Specifications are subject to change without notice
3
Model
MP-210U
MP-310U
MP-610U
MP-1010U
Rated Output
60W
120W
250W
350W
Output Regulation
Less than 3dB, from off-load to full load
Input sensitivity
Microphone : ≤3mV (unbalanced)
Line: ≤300mV (unbalanced)
Frequency Response
80Hz-16kHz (±3dB)
Distortion
Less than 1% (at 1kHz, 1/3 rated output voltage)
Ratio of
Signal to Noise
MIC: more than 71dB
LINE: more than 85dB
Tone
Bass: ±10dB（at 100Hz）
Treble: ±10dB（at 10kHz）
Protection
DC voltage; overload; short-circuit.
Mute
Input signals from MIC 1 override other input signals
Power
Requirements
AC 220-240V/50-60Hz
Power
Consumption
120W
250W
500W
650W
Outer Packing Size(mm)
(L×W×H)520×430×195
Unit Size (mm)
(L×W×H)418×338×88
Gross Weight
11.7kg
13.5kg
16kg
17kg
Net Weight
9.7kg
11.5kg
14kg
15kg
