• 5 •
To check the voltage level of the jump
starter’s internal battery, make sure the clips
are attached to their plastic storage holders
and not touching each other, and then turn
the rotary switch to the 12V position. The
display will indicate the battery’s voltage.
To check the voltage level of the vehicle’s
battery, make sure the switch in the OFF
position, then connect the clips to the
vehicle’s battery. The display will indicate
the battery’s voltage.
4.2 Charger LED Indicators
POWER (green) LED lit: The
charger is connected to AC power.
CHARGING STATUS LED (green)
pulsing slowly: The charger is
charging the jump starter’s internal
battery, or the battery is fully
charged and the charger is in
Maintain mode.
CHARGING STATUS LED
(yellow/orange) ashing rapidly:
The charger has detected a problem
with the battery. See Troubleshooting
for more information.
BAD BATTERY (red) LED lit:
The charger has detected a problem
with the battery. See Troubleshooting
for more information.
5. CHARGING THE INTERNAL BATTERY OF THE JUMP STARTER
IMPORTANT!
CHARGE IMMEDIATELY AFTER
PURCHASE, AFTER EACH USE AND
EVERY 30 DAYS, TO KEEP THE UNIT’S
INTERNAL BATTERY FULLY CHARGED
AND PROLONG BATTERY LIFE.
To check the internal battery’s charge
status, make sure the rotary switch is in the
OFF position, then press the display button
on the front of the jump starter. The digital
display will show the battery’s percent of
charge. A fully charged battery will read
100%. Charge the internal battery if the
display shows it is under 100%. Complete
charging may take up to 48 hours.
5.1 Grounding and AC Power Cord
Connections
IMPORTANT: Only use the charger that
was included with the jump starter to charge
the internal battery of the jump starter.
Using a different charger could result in
personal injury or property damage.
WARNING!
RISK OF ELECTRIC SHOCK OR FIRE.
This battery charger is for use on a
nominal 120V circuit. The plug must be
plugged into an outlet that is properly
installed in accordance with all local
codes and ordinances. The plug pins
must t the receptacle (outlet). Do not use
with an ungrounded system.
DANGER. Never alter the AC cord or plug
provided – if it does not t the outlet, have
a proper outlet installed by a qualied
electrician. An improper connection can
result in a risk of an electric shock or
electrocution.
An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in a risk of re and electric shock. If an
extension cord must be used, make sure:
• That the pins on the plug of the extension
cord are the same number, size and
shape as those of the plug on the charger.
• That the extension cord is properly wired
and in good electrical condition.
• That the wire size is large enough for the
AC ampere rating of the charger,
as specied:
Length of cord (feet) 25 50 100 150
AWG* size of cord 18 18 18 16
*AWG-American Wire Gauge
5.2 Charging the Jump Starter
with included Charger
1. Make sure the charger and jump starter
are placed on a dry, nonammable
surface. To charge the jump starter, plug
the charger into the charging port on the
front of the jump starter.
2. Conrm the AC outlet voltage matches
the input voltage of the charger.
3. Connect the charger to the AC wall
outlet and conrm that the green
POWER LED on the charger turns on.
4. Check that the green CHARGING
STATUS LED on the charger is pulsing
slowly, to indicate that charge process
has started. To see the status of the
charge, check the percentage shown
on the jump starter display.
5. When the jump starter display shows
100 (%), the internal battery is fully
charged and the jump starter is ready
to use. Complete charging may take up
to 24 hours.
NOTE: The green CHARGING
