DTS NICK NRG1201 User Manual

14
13- DISPLAY FUNCTIONS
DISPLAY FUNCTIONS
The NICK NRG 1201 display panel shows all the available functions . Using these
functions, it is possible to change some of the parameters and add some functions.
Changing the D.T.S. setting can vary the functions of the unit so that it does not
respond to the DMX 512 used to control it. Carefully follow the instructions below
before carrying out any variations or selections.
NOTE: the symbol shows which key has to be pushed to obtain the desired
function.
MENU
ENTER
DOWN
UP
DISPLAY
MAINS AC INPUT
90-260V 50 / 60Hz
MAINS AC OUTPUT
90-260V 50 / 60 Hz
(16A Max)
DMX OUT
DMX IN
DMX OUT
DMX IN
03.LDR006.F
03.LDR006.FW
03.LDR006.FFP
03.LDR006.FWFP
2dBi IP20 omnid.
antenna
DMX
IN
DMX
OUT
WIRELESS DMX
RECEIVER
RETROFIT
03.LA.126
