Content of Package
DC 5V / 1A power adaptor
Remote control unit
HDMI 4-IN / 2-OUT Matrix Switch
User’s Manual
ILLUSTRATION
Front Panel
Rear Panel
CONNECTION ILLUSTRATION
Application:
NOTE:
1. Users can use it to connect to a Home Theater system which supports a HDMI input.
2. For HD quality audio (Dolby
®
TrueHD, DTS
®
-HD Master Audio
TM
), or other audio formats that
need high bandwidth for audio transmission, please use HDMI connection for the HD audio
transmission.
