Dear record lover:
Please read these Instructions carefully
before you begin to set up and operate
your new automatic turntable. By doing
30, you will not only avoid faulty opera-
tion, but enjoy the full performance cap-
abilities of the 1219.
Move page 2 outward.
Unpacking
This instruction af
bought the 1219
component.
lies only if you have
a separately packed
See the separate unpacking instructions.
Install the platter by lowering it carefully
and slowly onto the shaft. An oll-soaked
felt washer will be pushed out as you
lower the turntable platter, thus oiling the
shaft, It can then be discarded
If your 1219 does not have a cartridge
installed, you will find installation instruc-
tions on page 11.
With the tonearm locked in place, install
the counterbalance at the rear of the
tonearm. You will find further instructions
for balancing the tonearm and setting
stylus force on pages 11 and 12 of these
Instructions. For the correct stylus force,
which depends on the make and model of
cartridge, follow the instructions provided
with the cartridge.
Installation on baso
‘Tho 1219 has threo mounting screws, each
with three positions, that allow you to in-
stall and remove your Dual from the top.
Hold the chassis above the base so that
the two spring-mounted footings at the
rear of the unit will ft Into their cut-outs,
AAs you lower the chassis, tilt the trans-
port
screw
with
your
thumbs
to
let
them
slip past the special notches. Then pro-
eed in the same way with the other two
transport
screws
and
place
the
spring-
mounted footings located on the left and
Tight front side of the turntable into the
cut-outs of the base,
‘Thon turn the screws clockwise until they
are seated in the top of the chassis. The
chassis is now spring-mounted
‘To secure the 1219 for transport, unscrew
the mounting screws, pull them up, then
continue to turn them counterclockwise
until they hold the chassis tight against
the
base.
To
prepare
the
1219
for
play
again, turn the three screws clockwise
until they loosen, then continue to turn
tuntil they are again seated in the chassis,
Note: After initial installation and after
‘every transport, allow the automatic me-
cchanism to adjust itself by operating the
1219 through one change cycle with the
tonearm locked on its rest (move the
‘operating lever to “start”).
Connections to power-line
For Duals already instal in either console or
SSrpact eyteme, see the instctions Yor the
The 1219 can be used with 50 or 60 Hz
AC, at 110 oF 220 volts. It is normally pre-
set for 220 volts, 50 Hz.
Je for which the 1219 has been
preset
can
be
read
on
the
voltage
selec-
tor. The frequency will be found on the
‘nameplate. Both are on the underside of
the chassis,
Fig.3
In units without @ voltage selector, the
correct
operating
voltage
must
be
set
by
inserting the motor power cable Into the
appropriate terminals, according to the
drawing in the power switch cov
The power switch is designed so that
preamplifiers or power amplifiers can be
Switched on or off automatically as the
4219 is turned on or off.
‘The load on the power switch must not
‘exceed 400 VA (volt-amperes). This foa-
ture is generally used with ali-transistor
amplifiers,
which
have
no
warm-up
delay.
‘The connection is made to contacts pro-
vided on the plug portion of the power
switch,
In this case, the line cord is to be fitted
with AMP plugs as follows:
B. No, 213 982; AMP-No. 160 565/1 (Fig. 2)
for 5-pole power supply plug
B.
No,
209458;
AMP-No.
42859/1
(Fig.
9)
for
4-pole
power
supply
plug
Connections to amplifior
For units already installed in systems, tho con
fectians, are. aiteagy me
SS
2 = lott ohannal
3 = Mant channel
Fig.4
The 1219 can be fitted with DIN 41 524
miniature connectors (Fig. 4) or with
RCA-type phono plugs (Fig. 5).
Fig.
Hf
the
unit
is
to
be
connected
to
equip-
ment
without
a power
transformer
(such
as
a small
radio
or
some
amplifiers),
the
‘Dual
should
be
grounded
to
prevent
pos-
sible
shock.
A
contact
is
available
for
this
purpose
on
the
power
connector.
(Figs.
2
and
3).
English
