Fig. 1
“start, the first record will drop and the
tonearm will it, move to the record, then
descend. If you wish to reject a record
that Is playing and change to tho next
fone of tho stack, move the switch to
start® again,
‘Automatic play without interruption
Once the record has been Iaid down on
tho platter, insert the puck through the
multiple-play spindle. It is recommended
to place a 45 rpm record on top of the
puck for added weight. The record will
then
play
continuously
without
interrup-
tion,
Fig. 12
Note: records already played can be lit-
‘ed back to the spindle for replay, or re-
moved altogether. There is no need to
remove the spindle in either case.
"The 45 rpm record spindle AS 12 is
available from audio dealers as an ac-
cessory.
Technical specifications
‘Mounting
the
cartridge
(pick-up)
The following instructions apply only it
your
1219
was
purchased
without
a
car-
fridge installed, or if you ever wish to
replace a cartridge. The 1219 will accept
any cartridge that weighs from 1 to 12
(grams, and that has standard 1/2" mount-
Ing centers,
Fig. 13
1. Remove the cartridge holder from the
tonearm head by pressing the tonearm
lift toward the rear. Hold the cartridge a
you do 80, or it will fall out
2. From the hardware supplied with el-
ther your Dual or with your cartridge, so-
lect a pair of spacers and scrows that
will
place
the
stylus
tip
21
mm
from
the
top of the hol
Fig. 14
9. A special gauge is also supplied to
assure correct mounting. (Fig. 14). The
‘cartridge
is
correctly
mounted
when
the
notch
in
the
gauge
encloses
the
stylus
tip,
and
when
the
stylus
tip,
viewed
from
the side is also within the area (A).
eft channel (white)
Lett around (be)
SSE SE, . '-|
Lah pron (gven) 5
Fig. 15
4. Connect each lead on the cartridge hol-
der to its corresponding pin on the ci
tridge. Each lead is color-coded as shown
in fig. 15.
5, Reinsert the cartridge holder in the
tonearm head from underneath, and lock
it by moving the tonearm lit forwar
Balancing the tonearm
4. With the tonearm locked on its rest
ost, and the stylus force dial sot at "0",
slip the shaft of the counterbalance onto
the rear of the tonearm. Do not tighten
the sot-scrow.
2. To make sure the tonearm is disen-
‘gaged from the cycling mechanism, move
the operating switch to "start", then ro-
tate the platter two or three timos by
hand,
Fig. 16
"
