Dual TBX10A - Installation: Connections and Controls; Connections and Controls

5
Phase Control
Power Indicator
Protect Indicator
Input Level Control
1 5
2 6
3 7
4 8
Crossover Frequency
Bass EQ
Fuse (15A)
Power / Input Connector
Connections and Controls
INSTALLATION
HIGH LEVEL
INPUT
1
2
3
4
5
6
7
8
