DCSW-1005/DCSW-1005PT can be used as an aggregation network TAP, in which a
copy of both outgoing and incoming packets associated with Port 1 (Target Port) is
forwarded to Port 5 (Monitor Port). Such a port-mirroring mechanism is hardware-
configured and therefore no software setup is necessary.
DCSW-1005/DCSW-1005PT further implements Port 1 and Port 2 for facilitating PoE
inline power pass through between these two ports. When Port 1 is connected with
an active Ethernet uplink with PoE inline power, the inline power is coupled to Port 2
to supply power to a powered device (PD) that is connected to Port 2. In the same
way, Port 1 also can receives inline power that is passed through Port 2 when Port 2
is connected with a PoE enabled uplink.
§5. SPECIFICATIONS
Standards IEEE 802.3 10BASE-T and 100Base-TX
Number of Ports
Five (5x) 1 auto-negotiation 10/100Mbps RJ45 ports with
Auto-MDI/MDIX
DC input 5VDC or power from a host USB port
LED Indicators
One power status LED and five port Link/Activity status
LEDs (each per port)
Port Mirroring
Target Part = Port 1
Monitor Port = Port 5
Pre-configured. A “copy” of Incoming and out-going
packets of Port 1 is forwarded to Port 5.
PoE Pass-Through
(DCSW-1005PT Only)
Between Port 1 and Port 2
Data Transfer Rate
14,880 pps for 10Mbps
148,809 pps for 100Mbps
MAC Address Size 2K (automatic update)
Packet Buffer Size 256KB RAM
Network Cable Type Cat.5, Cat.5E or better
Forwarding Method Store and forward
Dimension 4” x 2.5” x 0.9” (L x W xH)
EMI FCC Class B and CE
Warranty 1-year limited warranty
