3
Single Contact Grill
Double Contact Grill
Panini Grill
°C
°C
°C
°C
Contact Grill Parts:
1. Thermostat indicator (yellow light)
2. Temperature control
3. Power switch (green light)
4. Bottom box
5. Drip tray
6. Lower grill plate
7. Feed wire tube
8. Upper grill plate
9. Operation handle
10. Rubber feet
11. Wall spacer
12. Earth bolt
Note: The Double Contact Grill has 2 plugs,
one plug supplying power to each side.
This grill is a plug-in product but commercial safety regulations
require additional earthing to be carried out.
Only a suitably qualied technician should install the product.
There is an earth bolt at the back of the grill . Complying
fully with safety regulations, connect the earth wire with suitable
cable.
Thank you for purchasing this Dualit Contact Grill. The Dualit range includes three sizes: Single Contact Grill
for individual portions, Panini Grill - perfect for paninis and a Double Contact Grill for versatility.
Each model features robust cast iron plates with a sprung top plate for exiblity, a thermostatically-controlled
temperature range of 50-300°C and a removable drip tray for easy cleaning.
INSTALLATION
A suitable switch, fuse breaker and plug socket should be
installed near the grill.
The wall spacers on the back/side will ensure there is a air gap
around the machine.
You may see smoke coming from the machine when the
machine is rst switched on, this is normal.
103 2 1
9
8
7
6
5
4
103 2 1
9
8
7
6
5
4
101 2 3
9
8
7
6
5
4
12
11
12
11
12
11
