Dualtron spider User Manual
09
How to use the product
1) Productun folding
QR lever
QR lever
Finishing screw
Finishing screw
Locking slide
Locking slide
2. Raising handle post(Steering tube)
When unfolding the steering tube, raise
the handlebar while pushing the deck with
foot, and then lower the loking slide down
completely and tighten the right finishing
screws.
3. Fixing the folding part
When the QR lever is locked inward as
shown in the picture, the handle unfolding
is completed. If the folding lever is not
completely locked, a safety accident while
driving can be occurred. Before and after
running, always check if there is a play
in the folding part, and a folding part or
handle part, the bolt&nuts of all the fixing
parts of the product are properly tightened
and the fastened parts are not loosened.
1. Raise the handle post(Steering tube)
Release the QR lever, raise the locking
slide upwards, raise the steering tube,
then lower the locking slide downward.
