Ducane RGE13 - Performance; Cooling Performance; Heating Performance; Blower Performance

RCE13 Package Gas / Electric
Performance
Model
Cooling
Heating
BTUH SEER EER
S/T CFM
Input
BTUH
Output
BTUH
Efficiency
AFUE
Temp
Rise
Range °F
RGE13A24050(L)P
22,800 13.0 11.0 0.73 800
50,000 40,000
80%
30 - 60
RGE13A24075(L)P 75,000 60,000 35 - 65
RGE13A30050(L)P
28,000 13.0 11.0 0.74 1000
50,000 40,000
80%
30 - 60
RGE13A30075(L)P 75,000 60,000 35 - 65
RGE13A36075(L)P
34,000 13.0 11.0 0.71 1200
75,000 60,000
80%
35 - 65
RGE13A36100P 100,000 80,000 45 - 75
RGE13A42075(L)P
40,000 13.0 11.0 0.75 1400
75,000 60,000
80%
30 - 60
RGE13A42100(L)P 100,000 80,000 40 - 70
RGE13A48100(L)P
46,000 13.0 11.0 0.75 1600
100,000 80,000
80%
40 - 70
RGE13A48125P 125,000 100,000 45 - 75
RGE13A60100(L)P
56,000 13.0 11.0 0.72 1800
100,000 80,000
80%
40 - 70
RGE13A60125P 125,000 100,000 45 - 75
BlowerPerformance
Model
Blower
Tap*
(1 - 5)
CFM @ ext. Static Pressure in in. wc without lter, dry coil
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
RGE13A24***(L)P
1 500 480 420 340 290 240 --- ---
2 830 790 760 710 640 600 560 520
3 950 920 890 850 810 740 700 660
RGE13A30***(L)P
1 630 550 470 420 380 320 --- ---
2 1020 990 960 920 890 850 790 740
3 1100 1060 1030 1010 990 950 900 840
RGE13A36***(L)P
1 760 680 600 550 490 --- --- ---
2 1250 1210 1180 1130 1090 1060 1010 960
3 1370 1330 1280 1250 1210 1170 1120 1040
RGE13A42***(L)P
1 860 780 710 660 600 560 --- ---
2 1460 1400 1340 1280 1230 1180 1140 1100
3 1600 1560 1500 1450 1400 1320 1230 1150
RGE13A48***(L)P
1 970 890 820 780 740 680 --- ---
2 1680 1640 1590 1540 1450 1330 1260 1180
3 1890 1820 1730 1620 1540 1430 1300 1210
RGE13A60***(L)P
1 1200 1130 1070 990 930 860 - -
2 1870 1840 1800 1760 1700 1650 1600 1550
3 2010 1970 1930 1890 1850 1810 1760 1700
Add .10 Duct Static for Downflow CFM
* Tap 1 - Fan Only
Tap 2 - Low Static Cooling
Tap 3 - High Static Cooling
Taps 4 & 5 designed for Heating mid point temperature rise @:
Tap 4 - Nominal .2 ESP
Tap 5 - Nominal .5 ESP
- Page 3 -
Model
Voltage/HZ/
Phase
Voltage
Range
Min.
Circuit
Amp.
Max.
Over
Current
Device
(amps)
Compressor
Condenser
Fan Motor
Indoor
Blower Motor
Exhaust
Motor
Refrig.
Charge
Weight
(lbs.)
Rated
Load
(amps)
Locked
Rotor
(amps)
Rated
Load
(amps)
Rated
HP
Nom.
RPM
Rated
Load
(amps)
Rated
HP
Rated
Load
(amps)
Rated
HP
RGE13A24050(L)
208-230/60/1 197-253 15.7
20
8.3 43 1.2 1/4 1075 4.1 1/2 0.7 1/3 82
370
RGE13A24075(L)
380
RGE13A30050(L
208-230/60/1 197-253 19.3
25
11.2 54 1.2 1/4 1075 4.1 1/2 0.7 1/3 82
375
RGE13A30075(L)P
385
RGE13A36075(L)P
208-230/60/1 197-253 21.7
30
13.1 74 1.2 1/4 1075 4.1 1/2 0.7 1/3 117
405
RGE13A36100P
415
RGE13A42075(L)P
208-230/60/1 197-253
25.8
40
16.0 88 1.7 1/3 1075
4.1 1/2
0.7 1/3 90
430
RGE13A42100(L)P
27.5 5.8 3/4 445
RGE13A48100(L)P
208-230/60/1 197-253 28.4
40
16.7 84 1.7 1/3 1075 5.8 3/4 0.7 1/3 104
450
RGE13A48125P
460
RGE13A60100(L)P
208-230/60/1 197-253 38.7
60
25.0 134 1.7 1/3 1075 5.8 1 0.7 1/3 140
495
RGE13A60125P
505
