Ducati DESMOSEDICI RR User Manual

50
E
Fuel tank plug (fig. 39)
Opening
Lift the protection lid (1) and fit the ignition key into the lock.
Turn the key clockwise 1/4 turn to unlock.
Lift the plug.
Closing
Refit the plug with the key in it and push it down into its seat.
Turn the key anticlockwise to its initial position and take it
out. Close the lock protection lid (1).
Note
The plug can only be closed with the key in.
Warning
Always make sure you have properly refitted (see page
64) and closed the plug after each refuelling.
1
fig. 39

Ducati DESMOSEDICI RR Specifications

General

Displacement	989 cc
Transmission	6-speed
Frame	Tubular steel trellis
Front Suspension	Öhlins 43 mm upside-down fork
Seat Height	830 mm (32.7 in)
Power	200 hp (147.1 kW) @ 13, 800 rpm
Torque	11.8 kgm @ 10, 500 rpm
Rear Suspension	Öhlins shock absorber
Front Brakes	Dual 330 mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Dry Weight	171 kg
Fuel Capacity	15 L
