Ducati HYPERMOTARD 1100 S User Manual

35
E
The immobilizer system
For improved anti-theft protection, the motorcycle is
equipped with an IMMOBILIZER, an electronic system that
inhibits engine operation whenever the ignition switch is
turned off.
Accommodated in the handgrip of each ignition key is an
electronic device that modulates an output signal. This signal
is generated by a special antenna incorporated in the switch
when the ignition is turned on and changes every time. The
modulated signal acts as a password and tells the CPU that
an "authorised" ignition key is being used to start up the
engine. When the CPU recognises the signal, it enables
engine start-up.
Keys
(fig. 21)
The Owner receives a set of keys comprising:
- 2 (BLACK) keys B
These keys contain the immobilizer system code.
Note
Your Ducati dealer might ask you to submit the Code
Card for some service operations.
The black keys (B) are regular ignition keys and are used to:
- start up the engine
- open the lock of the fuel tank filler plug
- open the seat lock.
Note
The two keys have a small plate (1) attached that
reports their identification number.
1
B
fig. 21
UM_HYM1100_S_09_e.book Page 35 Monday, June 16, 2008 1:06 PM

Ducati HYPERMOTARD 1100 S Specifications

General

Displacement	1078 cc
Transmission	6-speed
Rear Brake	245 mm disc, 2-piston caliper
Wheelbase	1455 mm (57.3 in)
Seat Height	845 mm (33.3 in)
Frame	Tubular steel Trellis frame
Engine Type	L-Twin cylinder, 2 valves per cylinder, Desmodromic, air cooled
Max Power	66.2 kW (90 hp) @ 7750 rpm
Max Torque	102.9 Nm (76 lb-ft) @ 5000 rpm
Fuel Capacity	12.4 liters (3.3 US gallons)
