Caratteristiche tecniche
Technical specification
sezione / section
C 1.1
12
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
Gearbox
Cooling system
Front wheel
Front suspension
Rear wheel
Minimum 8 bar (min.)
Max. allowed difference 2 bar (max.)
Reference Standard value Max. allowed value
Gearbox shafts Axial play 0.05 – 0.20 mm
Gearbox drum Axial play 0.10 - 0.40 mm
Gear selector fork Fork sliding shoe thickness 3.90-4.00 mm
Fork – gear clearance 0.070- 0.285 mm 0.4 mm
Reference Technical specifications
Type Air: heat is discharged through the large
fins of both cylinder-head assemblies
Reference Standard value Max. allowed value
Tread min. thickness In the most worn position 2 mm
Tyre pressure Cold 2.1 bar - 2.3 bar
Wheel shaft eccentricity On 100 mm 0.2 mm
Wheel rim eccentricity Radial 0.8 mm 2 mm
Axial 0.5 mm 2 mm
Reference Technical specifications
Type Upside-down hydraulic fork
ø 43 non
adjustable
Travel along leg axis 130 mm
Front fork Non adjustable
Oil quantity per leg 0.400 cu dm
Reference Standard value Max. allowed value
Tread min. thickness In the most worn position 2 mm
Tyre pressure Cold 2.2 bar - 2.4 bar
Swingarm shaft eccentricity On 100 mm 0.2 mm
Wheel rim eccentricity Radial 0.8 mm 2 mm
Axial 0.5 mm 2 mm
Chain Make
Type
D.I.D.
520 V L 4
Dimensions 5/8" x 1/4"
No. of links 106
Reference Standard value Max. allowed value
