12
E
7) EOBD light (amber).
When on, engine operation is inhibited. It goes out after a
few seconds (usually 1.8 - 2 sec.).
8) Tachometer (km/h).
Gives road speed.
a) LCD (1):
- Odometer (km).
Gives total distance covered.
- Trip meter (km).
This function indicates the distance covered since the
meter was last reset or since the fuel reserve is on.
- Trip fuel meter.
When the reserve light is on, it displays mileage covered
with fuel reserve.
9) Revolution counter (rpm).
Shows the engine rotation speed/minute.
b) LCD (2):
- Clock
- Oil temperature
7
8 9
a
b
fig. 4.2
