Ducati MONSTER 400 User Manual

75
E
Cable colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Note
The system wiring diagram is at the end of this manual.
Legend to fuse box (1, fig. 58)
Pos. El. item Rat.
1-9 Main 30 A
2-10 Fuel pump, injectors, coils 20 A
3-11 Key sense 10 A
4-12 ECU power supply 3 A
5-13 Passing 7.5 A
6-14 Parking lights, instrument panel, high/
low beam
15 A
7-15 Stop, horn 10 A
8-16 Side stand 5 A

Ducati MONSTER 400 Specifications

General

Displacement	398 cc
Final Drive	Chain
Front Tire	120/60 ZR17
Rear Tire	160/60 ZR17
Seat Height	770 mm
Cooling System	Air cooled
Fuel System	Carburetor
Front Brake	Disc
Rear Brake	Disc
Frame	Tubular steel trellis
Wheelbase	1430 mm
