E
68
Cable colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Note
The system wiring diagram is at the end of this
manual.
Legend to fuse box (1, fig. 58)
Pos. El. item Rat.
1-9 Main 30 A
2-10 Fuel pump, injectors, coils 20 A
3-11 Key sense 10 A
4-12 ECU power supply 3 A
5-13 Passing 7.5 A
6-14 Parking lights, instrument
panel, high/low beam
15 A
7-15 Stop, horn 10 A
8-16 Side stand 5 A
