This document describes the Portable Mini Voice Recorder, model Q63, providing a comprehensive guide to its functions, specifications, usage, and maintenance.

Function Description

The Q63 is a compact voice recorder designed for various recording needs. It supports normal recording, voice-activated recording (VAR), and can also function as a hearing aid. The device allows for playback of recordings and music, and offers features like fast forward/backward, volume adjustment, and file deletion directly on the device or via a computer. It also includes a time synchronization tool and password protection for files.

Important Technical Specifications

Product Size: 1.1 x 1.1 x 0.3 inches
Product Weight: 0.39oz
Recording Format: WAV
Play Format: MP3/WAV/WMA
Distortion: <0.008%
Frequency Response: 20Hz-20KHz
Sampling Rate: 48KHz
Signal to Noise Ratio: >50db
Headphone Interface: 3.5mm
USB Interface: USB 2.0
Charging Time: 2-3 hours
Support Operation System: Windows 98/ME/2K/XP/Vista; Mac OS10 (Linux not supported)

Usage Features

The Q63 features a three-steps switch for easy operation:

Power On (Normal Recording): Push the switch to the left (microphone icon). The indicator light will be red for 5 seconds, then flash red 3 times, and turn off, indicating normal recording has started.
Voice Activated Recording (VAR): Push the switch to the middle (V icon). The indicator light will be red for 5 seconds, then flash blue 3 times, and turn off, indicating voice-activated recording has started.
Power Off (Saving): Push the switch to the right (power icon). The indicator light will be red for a few seconds and then turn off, saving the recordings.

Checking Recording Status:

In "normal recording" state, long press "+" or "-" button. Indicator flashes red once for normal recording.
In "voice activated recording" state, long press "+" or "-" button. Indicator flashes blue once for VAR recording.

Playback:

At Device: Connect an audio cable and earphone. Turn on the device. After the light goes out, it enters "Playback" status and plays the newest recording.
At Computer: Connect the recorder to your PC. Navigate to "My PC(Window)/Finder(Mac) - VOICE-RECORD-VOICE" to access files. Playback requires a WAV format supported player (Windows Media Player for Windows, VLC Media Player for Mac). Windows 10 GROOVE player is not compatible.
Music/Recordings Playback Switch: Press the "-" button once to switch between music and recording playback. Red light indicates recording playback, blue light indicates music playback. If no file, it flashes red/blue alternatively.
Pause: Press "+" and "-" at the same time to "Pause" playback. Press "+" or "-" button twice to exit "Pause" state. Indicator light flashes purple at "Pause" status.
Volume Up/Down/Next File: Long press "+" / "-" button to increase/lower volume. Press "+" button once to skip to the next file.
Fast Forward/Backward: Plug in audio cable & earphone, push switch to "microphone" position. Long press "-" button for 5 seconds. At "playback" state, long press "+" or "-" button to fast forward/backward. This function needs to be reset each time and volume cannot be adjusted during this operation.

Extended Functions:

Delete File at Device:
- Delete Current Playing File: Enter "Pause" state (press "+" and "-" simultaneously, light flashes purple). Long press "-" button until blue light flashes (indicating successful deletion).
- Delete All Files: At "pause" state, long press "-" and "+" button at the same time until red light flashes (indicating successful deletion). Note: This deletes all recording/music files.
Recording While Charging: Connect the device to a computer/charger via USB cable. Enter "Charging status". Turn on the device by long pressing "+" button until the light goes out. It then enters "Recording while charging" state. Both VOR and normal recording functions can be used.
Listening While Recording - Hearing Aid: Push the switch to "microphone" or "V" position. After the red light goes off, plug in the audio cable & earphone. Wait for about 3 seconds, it enters "Listening While Recording" state.
Encryption Tool - Password Protected: Files will require a password to open when connected to a computer. Follow instructions in the "Instruction for Encryption Tools" file on the device drive or refer to the YouTube video: https://youtu.be/c7nWluGLbHM.
Time Synchronization Tool: Use the "FACOTRY" file or "Time Synchronization Tool" to update date/time.
- Method 1 (Windows): Connect to computer, open "Time Synchronization Tool" folder. Select "SET DISK TIME" and check if the time matches your computer. Click "SetTime" to complete.
- Method 2 ("FACTORY" Setting for Mac/Windows): Connect to computer, open "FACTORY" file. Change number after DATE (YY-mm-dd, e.g., 2021-06-01) and Time (HH-mm-ss, e.g., 11:28:03). Click "File-Save" to save.

OTG Connection to Phone:

The device supports quick file transmission via OTG function. Turn off the device first.
Android Phone: Connect the original USB cable with the 2-in-1 OTG cable. Plug the original USB cable to the recorder, then plug the 2-in-1 OTG cable into your Android phone.
iPhone (iPhone 8/iOS 13 and above): Connect the original USB cable & OTG-for-iPhone cable to the device & phone. Find App "File" on phone. Click "Browse" to find recorder's disk [VOICE]. Open file folder "Voice" to play/download/delete recordings. (OTG-for-iPhone cable not included).
Ensure Android mobile phone supports OTG function and it is enabled. Make sure the white original USB cable is always connected to the recorder and the OTG cable port is connected to the phone.

Maintenance Features

Charging: Two ways to charge:
- With computer: Connect directly via USB cable.
- With charger: Plug into an adapter (suggest 500mA-1000mA or 5V).
- Charging time is generally 2-3 hours. The indicator light is red when charging and turns blue when fully charged. Avoid charging for over 10 hours.
Connecting to Computer: Turn off the device first. Use the original white USB cable. Disconnect using "Safely Remove Hardware" (Windows) or "Eject" (Mac OS). Use the original USB data cable, not just a charging cable, to ensure recognition.
Troubleshooting:
- Format/Reboot: For drive-related issues (full memory, messy file names, large file size, damaged files), formatting the device often works. For product malfunction (not turning on, indicator light not responding, always lit red), rebooting the device often works. Always back up files before formatting or rebooting.
- Not Recording/Not Turning On: Check power and memory. Ensure correct operation. Format or reboot if needed. Contact support for free replacement if the issue persists. If unused for a long time, charge it.
- Indicator Light Not Responding/Always Lit: Wrong operation or software damage. Follow instruction video to reboot or contact support.
- Not Recognized by Computer: Use original USB cable. Check if it's a data cable, not just charging. Some tools are EXE format and may not be supported by Mac; find transformation software. Check "Computer-Organize-Properties-Device Manager-Disk drive/Universal Serial Bus Controller" and send a screenshot to support.
- Complicated Operation: Refer to video instructions or contact support.
- Voice Activated Recording Not Working: Confirm correct operation. Adjust VOR sensitivity parameter in the "FACTORY" file (0-7 level; lower number for higher sensitivity, higher number for lower sensitivity). Default is 3. Record at a certain distance and sound level (over 60db). Reboot the device.
- Not Charging/Charging Too Hot: Use original USB cable. Check if the cable is damaged. Ensure charger output is 500mA-1000mA or 5V. Avoid charging for over 10 hours. Turn off the device before charging.
- Recordings Not Playing on Computer: Use WAV-format supported media player (Windows Media Player or VLC Media Player). Windows 10 GROOVE player is not compatible.
- Poor Recording Quality: Record in quiet environments, place the recorder stably, avoid friction. Adjust microphone sensitivity (GAIN) in the "FACTORY" txt file. Use high-quality earphones for listening.
General Precautions: Turn off the device before charging or connecting to a computer. Always turn off the device after recording to save files and prevent data loss. Use the original white USB cable. Regularly back up files to prevent loss.
Missing Parts/Defective Device: Contact support for a new replacement or full refund. No need to return.
Digital Manual/Tools: Contact support for download links and instructions.
Customer Service: Gurantee 100% satisfactory customer service. Contact ymkeji@hotmail.com for any problems.
