Duluth Forge FVFLC18-1 - Model FVFLC18-1 Log Installation; Step 1: Rear Log Bracket; Step 2: Middle Log Bracket; Step 3: Front Log Bracket

5
www.factorybuysdirect.com
200235-01C
Log #5
Log #6
Log #4
Log #3
5. Place log #5 into notches in logs #1 and
#3 at the right as shown.
6. Place log #6 into notches in logs #3 and
#4 as shown.
INSTALLING LOGS
3. Place log #3 into the area between the
front log bracket and grate ngers.
4. Place log #4 into notches in logs #1 and
#3 at the left as shown.
