35
‘Enviro’ Seed Drill Complete Assembly
*N Where N = number of coulters fitted. e.g. 19 for 19 Run Machine (see table below for part number).
Part numbers for different width machines
Item 15 Run 17 Run 19 Run 21 Run 23 Run 26 Run
26 22218 22218 22220 22220 22222 22222
27 22593 22593 22646 22646 22648 22648
28 22586 22586 22636 22636 22638 22638
29 22604 22604 22614 22614 22626 22626
30 22605 22605 22615 22615 22627 22627
31 22388 22389 22392 22393 22396 22400
32 22561 22561 22563(LH) Plus 22571(RH) 22564 22564
33 22915 22915 22917 22917 22919 22919
34 22219 22219 22221 22221 22223 22223
ITEM PART No. DESCRIPTION QTY
1 Refer Page 36/37 Mainframe & Drawbar 1
2 Refer Page 38/39 Wheel Arms 1
3 Refer Page 40/41 Hydraulics 1
4 Refer Page 42/43 Wiring & Lighting Kit 1
5 Refer Page 44/45 Coulter Assembly Complete *N
6 45019 M12 x 30 Class 8.8 Zinc Plated Bolt 24
7 Refer Page 54 Clutch Shaft Assembly 1
8 45140 M16 Nylock Nut 24
9 Refer Page 58/59 Box Drive Shafts 1
10 Refer Page 62/63 Seedbox Assembly 1
11 Refer Page 64 Agitator Drives 1
12 Refer Page 65 Agitator Shaft Assembly 2
13 Refer Page 66/67 Seeder Assembly *N
14 Refer Page 61 Gearbox Final Assembly Pt No 22054 1
15 Refer P 53,56.57 Drive Chains 1
16 Refer Page 60 Clutch Assembly 1
17 22051 Crank Arm & Handle Assembly 1
18 22198 RH Cover Plate 1
19 22199 RH Front Cover Plate 1
20 22200 LH Rear Cover Plate 1
21 22201 LH Front Cover Plate 1
22 17905 12.4/11 x 28 x 10ply Wheel Assembly 2
23 22584 Latch Chain (12 links) 2
24 22743 Plastic Guard (Clutch to Gearbox) 1
25 22527 Fibreglass Guard (Gearbox to Seedboxes) 1
26 Refer Below Frame Rear Beam Assembly 2
27 Refer Below Front Footboard Assembly 1
28 Refer Below Rear Footboard Assembly 1
29 Refer Below Guard Rail Assembly (Short) 1
30 Refer Below Guard Rail Assembly (Long) 1
31 Refer Below Pressure Bar Assembly 1
32 Refer Below Calibration Tray Assembly 1
33 Refer Below Ripstop Weather Skirt 2
34 Refer Below Front Spreader Beam Assembly 1
35 45292 7/16” x 1 1/2” Lynch Pin 2
36 45023S M12 x 50 Class 8.8 Zinc Plated Set Screw 2
37 45131 M12 Class 8.8 Zinc Plated Hex Nut 2
38 45139 M12 Nylock Nut 18
39 45141 M20 Nylock Nut 2
40 45159 M12 Heavy Duty Zinc Plated Flat Washer 20
41 45161 M20 Heavy Duty Zinc Plated Flat Washer 2
42 45063 M20 x 55 Class 8.8 Zinc Plated Bolt 2
43 44991s M8 x 16 Class 8.8 Zinc Plated Set Screw 2
44 44992s M8 x 20 Class 8.8 Zinc Plated Set Screw 10
45 45157 M8 Heavy Duty Zinc Plated Flat Washer 12
46 45165 M8 Zinc Plated Spring Washer 12
47 45341 M10 Zinc Plated Wing Nut 2
To Next Page
