37
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Mainframe & Drawbar
ITEM PART No. DESCRIPTION QTY
1 22194 LH Endplate Assembly 1
2 22195 RH Endplate Assembly 1
3 22208 Coulter Adjustment Rod Assembly 2
4 22293 Ram Anchor Pin 2
5 22262 Clevis Pin (Wheel Arm, Tabbed) 2
6 22752 LH Wheel Arm Welded Assembly (refer page 36/37) 1
7 22753 RH Wheel Arm Welded Assembly (refer page 36/37) 1
8 43499 Stop Collar Set 1
9 43935 4” x 12” Master Rephasing Ram 1
10 43936 3.75” x 12” Slave Rephasing Ram 1
11 45272 R Clip (S12) or (AG7) 4
12 22270 Clevis Spacer 4
13 45134 M24 Class 8.8 Zinc Plated Hex Nut 4
14 45001s M10 x 20 Class 8.8 Zinc Plated Set Screw 4
15 22310 Draw Bar Clevis Pin 1
16 22318 Draw Bar Axle 1
17 22322 Draw Bar Final Assembly 1
18 22449 Hydraulic Valve Support Assembly 1
19 31478 1 Tonne Jack & Stub Assembly 1
20 31483 Jack Support Bracket Assembly 1
21 43395 Heavy Duty Ratchet Ram/Turnbuckle 1
22 - Turnbuckle Pin (Supplied with turnbuckle) 1
23 4800315 Hose Support 1
24 Refer Below Frame Front Beam Assembly 1
25 Refer Below Carrier Beam Assembly 1
26 Refer Below Pressure Bar Assembly 1
27 45038 M16 x 40 Class 8.8 Zinc Plated Bolt 24
28 45052 M16 x 140 Class 8.8 Zinc Plated Bolt (Carrier Bar Ties) 6
29 45160 M16 Heavy Duty Zinc Plated Flat Washer 12
30 45141 M20 Nylock Nut 5
31 45140 M16 Nylock Nut 22
32 45034 M12 x 130 Class 8.8 Zinc Plated Bolt 1
33 45035 M12 x 140 Class 8.8 Zinc Plated Bolt 1
34 45139 M12 Nylock Nut 2
35 45292 7/16” x 1 1/2” Lynch Pin 2
36 45067 M20 x 75 Class 8.8 Zinc Plated Bolt 2
37 45018S M12 x 25 Class 8.8 Zinc Plated Setscrew 4
38 45418S M10 x 25 Zinc Plated Setscrew 2
39 45158 M10 H/D Zinc Plated Flat Washer 2
40 45166 M10 Zinc Plated Spring Washer 2
41 22305 Swivel Towhitch 1
42 45042 M16 x 60 Class 8.8 Zinc Plated Bolt 4
43 45084 M20 x 240 Class 8.8 Zinc Plated Bolt 1
44 45141 M20 Nylock Nut 1
45 43032 Chains No.3 2
To Next Page
