39
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Wheel Arms
ITEM PART No. DESCRIPTION QTY
1 22753 RH Wheel Arm Welded Assembly 1
2 22752 LH Wheel Arm Welded Assembly 1
3 22271P# Cover Plate 1
4 22282P End Cap 2
5 22292 Wheel Arm Pivot Pin 2
6 22032 6 Square x 22 Long Key 1
7 22295 25T x 1/2” Pitch Primary Sprocket 1
8 22297 19T x 1/2” Pitch Transfer Double Sprocket 1
9 22769 Drive Axle 1
10 22303 2.5mm Nylon Spacer 2
11 22767 Drive Hub 1
12 22768 Plain Wheel Hub 1
13 22465 1/2” x 131 Link BS Chain 1
14 43388 1/2” Pitch Joiner Link 1
15 31285 Chain Tensioner & Shoe Assembly 1
16 30273 Chain Tensioner Nylon Shoe Only (Spares) 2
17 43030 32009 Bearing 2
18 43033 32012 Bearing 3
19 43031 32010 Bearing 1
20 22264 Axle Washer 36mm Bore 2
21 22328P Cover Plate 1
22 43426 Glacier Bush (45mm Bore) 4
23 43427 Glycodur Bush (45mm Bore) 1
24 43644 Freewheel Hub Assembly 1
25 43439 (CC 55 85 08) Oil Seal 1
26 47610 M30 x 1.5 Castle Nut 1
27 43040 (TC 8010010) Oil Seal 3
28 43431 3” Diameter Dust Cap 1
29 22766 M36 x 2 Castle Nut 1
30 45313 M5 x 50 Split Pin 1
31 45317 6.3 x 75 Split Pin 2
32 22765 Bearing Spacer 3
33 45040S M16 x 50 Class 8.8 Zinc Plated Set Screw 16
34 45148 M16 Wheel Nut 16
35 45168 M16 Zinc Plated Spring Washer 16
36 45001s M10 x 20 Class 8.8 Zinc Plated Set Screw 6
37 45018s M12 x 25 Class 4.6 Zinc Plated Set Screw 4
38 45166 M10 Zinc Plated Spring Washer 6
39 45131 M12 Class 8.8 Zinc Plated Hex Nut 1
40 45139 M12 Nyloc Nut 1
41 43118 M8 x 1.25 Pitch Straight Grease Nipple 4
42 22285 Nylon Spacer Washer 4
43 44951s M6 x 16 Class 4.6 Zinc Plated Set Screw 3
44 45164 M6 Zinc Plated Spring Washer 3
45 45150 M6 Light Flat Washer 3
46 45158 M10 Heavy Duty Zinc Plated Flat Washer 6
47 47611 M36 x 4 Castle Nut 1
To Next Page
