Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Double Disc Assembly
ITEM PART No. DESCRIPTION QTY
1 22203 Double Disc Casting Welded Assy (Mk2) 1
2 22136 Plastic Spacer 2
3 43352 Vee Ring Seal V-40A 2
4 45154 M16 Light Flat Washer Z/P 2
5 Refer Page 50 Disc Sub Assembly 2
6 22079 Bearing Sleeve 2
7 22078 Seal Collar 2
8 45040 M16 x 50 Bolt Grade 8.8 Z/P 1
9 22082 Disc Retaining Bolt (Left Hand Thread) 1
10 22077 Dust Cap 16mm Bore 2
11 22114 Spring Rod Assy 1
12 22109 Bottom Spring Retainer 1
13 17753 Inner Spring 1
14 17752 Outer Spring 1
15 17750 Top Spring Cap 1
16 22110 Spring Rod Cap 1
17 45141 M20 Nyloc Nut 1
18 22069 D/Disc Scraper Mounting Strap 1
19 45152 M10 Light Flat Washer Z/P 1
20 45166 M10 Spring Washer Z/P 1
21 45001s M10 x 20 Set Screw Grade 8.8 Z/P 1
22 45136 M6 Nyloc Nut 1
23 22086C R/H Scraper Casting 1
24 22087C L/H Scraper Casting 1
25 22088 Scraper Hinge Stainless 1
26 22070 Double Disc Scraper Tensioner 1
27 45156 M6 HD Flat Washer Z/P 1
28 44955 M6 x 30 Bolt Grade 8.8 Z/P 1
29 45139 M12 Nyloc Nut 1
30 45023 M12 x 50 Bolt Grade 8.8 Z/P 1
To Next Page
