51
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Disc Assembly
ITEM PART No. DESCRIPTION QTY
1 45001s M10 x 20 Set Screw Grade 8.8 Z/P 6
2 22002 380 x 4mm Plain Disc x 6 Hole 1
3 22081 Seal Face Ring 1
4 11351 Bearing 6305 1
5 17537 Bearing Housing 6 hole 1
6 45138 M10 Nyloc Nut 6
7 22079 Bearing Sleeve 1
8 22078 Seal Collar 1
9 43352 Vee Ring Seal V-40A 1
10 22077 Dust Cap (16mm Bore) 1
1 2 3 4
7 8 9
10
5 6
Note: Item 9 Vee Ring Seal
Orientation
SEE NOTE
To Next Page
