53
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Press Wheel Assembly
ITEM PART No. DESCRIPTION QTY
1 23536 Tension Spring 7.5kN/m 1
2 24451 Upper Jaw Assy RH 1
3 45321 D Shackle 5/16” 1
4 45139 M12 Nyloc Nut 5
5 23510 Jaw Lock Pin Assembly 1
6 23506 Spring Slide 1
7 23525 Tension Spring 1
8 23504 Upper Jaw Spacer 1
9 45158 M10 Heavy Duty Flat Washer Z/P 2
10 45166 M10 Spring Washer Z/P 2
11 45001s M10 x 20 Grade 8.8 Z/P S/Screw 2
12 29267 Scraper for 15” x 80mm Wedge Press Wheel 1
13 45025 M12 x 60 Grade 8.8 Z/P Bolt 5
14 23515 Lower Jaw Assembly 1
15 24450 Upper Jaw Assy LH 1
16 24452 Jaw Pivot Pin 1
17 24456 Bush Top Hat 25x30x32 2
18 23503 Spring Retainer 1
19 45187 M10 x 16 Socket Head Grubscrew 1
20 45051 M16 x 130 Grade 8.8 Bolt 1
21 23551 RH Press Wheel Arm 2
22 45119 M16 Grade 8.8 Hex Half-Nut 1
23 45168 M16 Spring Washer Z/P 1
24 10283 Oil Seal 2
25 61022 Bearing Mount 2
26 11351 Bearing 6305 2
27 43573 Press Wheel Solid Vee Wedge 1
28 61021 Spacer 1
29 23550 LH Press Wheel Arm 1
To Next Page
