57
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Clutch Shaft Assembly
ITEM PART No. DESCRIPTION QTY
1 43386 “Y” Bearing YET205 (25mm) 2
2 30359 Pressed Steel 3 Bolt Bearing Housing PF52 (2 Flanges) 2
3 22158 Clutch Actuating Arm Assembly 1
4 22144 Clutch Shaft (25mm) Quick Change 1
5 22159 Clutch Arm Return Spring 1
6 22165 Clutch Chain Assembly 1
7 22480 Chain Tensioner Arm Assembly 1
8 22522 Tensioner Torsion Spring LH 1
9 22535 Chain Tension Nylon Roller 1
10 45370 M16 Starlock Fixing Washer 1
11 45276 6mm Roll Pin x 60 long 1
12 45030 M12 x 90 Class 8.8 Zinc Plated Bolt 1
13 45122 M6 Class 8.8 Zinc Plated Hex Nut 3
14 45130 M10 Class 8.8 Zinc Plated Hex Nut 1
15 45131 M12 Class 8.8 Zinc Plated Hex Nut 1
16 45136 M6 Nylock Nut 9
17 45138 M10 Nylock Nut 4
18 45139 M12 Nylock Nut 1
19 45140 M16 Nylock Nut 1
20 45150 M6 Zinc Plated Light Flat Washer 1
21 45151 M8 Zinc Plated Light Flat Washer 6
22 22474 Chain Tensioner Spacer (6mm) 1
23 45165 M8 Zinc Plated Spring Washer 6
24 44952s M6 x 20 Class 8.8 Zinc Plated Set Screw 1
25 44991s M8 x 16 Class 8.8 Zinc Plated Set Screw 6
26 45368 M10 Starlock Fixing Washer 1
27 45041 M16 x 55 Class 8.8 Zinc Plated Bolt 2
28 45002s M10 x 25 Class 8.8 Zinc Plated Set Screw 1
29 22162 Hectaremeter Sensor Mounting Bracket 1
30 22161 Clutch Final Assembly Refer P 28 1
31 44571K Jackal v3 Hectaremeter Kit. Contains items 32 - 39 -
32 44572 Jackal v3 Speed & Area Meter 1
33 44573 Owner's Manual Jackal v3 1
34 43403 Hectaremeter Sensor w/o Nuts AA-110P/5 1
35 43404 Hectaremeter Clamp & Magnet AA-117 1
36 43154 Hectaremeter Sensor Brass Nut 2
37 44028 Window Mount AH-407 1
38 44031 7.5m Cable (2 way) AC-088 1
39 44574 Power Cable Assy Jackal v3 (complete: comprises items 39-42 below) 1
40 44029 Power Cable AC-105 1
41 44575 Cable S/Assy Jackal v3 (short 2way) 1
42 44146 11 way Terminal Block P321 Green 1
To Next Page
