Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Box Drive Chain Details
ITEM PART No. DESCRIPTION QTY
1 22471 1/2” x 81 Link BS Chain (Clutch to Gearbox Input) 1
2 22468 1/2” x 119 Link BS Chain (Gearbox to Front Seed Box) 1
3 22469 1/2” x 95 Link BS Chain (Gearbox to Rear Box Idler) 1
4 22470 1/2” x 103 Link BS Chain (Rear Box Idler to Rear Seed Box) 1
5 25982 15/19 Tooth 1/2” Pitch 25mm Bore Change Sprocket 1
6 25982 15/19 Tooth 1/2” Pitch 25mm Bore Change Sprocket 1
7 22044 15 Tooth 1/2” Pitch 20mm Bore Sprocket (Gearbox Output) 2
8 22023 6 x 6 x 85 Long Key (Gearbox Input Drive Adapter) 1
9 22538 6 x 6 x 25 Long Key (Drive Sprockets) 6
10 43386 “Y” Bearing YET205 (25mm) 2
11 30359 Pressed Steel 3 Bolt Bearing Housing PF52 (2 Flanges) 2
12 22144 Clutch Shaft (25mm) Quick Change 1
13 22480 Chain Tensioner Arm Assembly 2
14 22522 Tensioner Torsion Spring LH 1
15 22523 Tensioner Torsion Spring RH 1
16 22475 Chain Tensioner Spacer (20mm) 1
17 22535 Chain Tension Nylon Roller 2
18 22050 Crank Adaptor 1
19 45130 M10 Class 8.8 Zinc Plated Hex Nut 6
20 45140 M16 Nylock Nut 2
21 45160 M16 Zinc Plated Heavy Duty Flat Washer 1
22 45181 M8 x 12 Socket Head Grubscrew 6
23 45180 M8 x 10 Socket Head Grubscrew 2
24 22197 M10 Retaining Stud 2
25 45166 M10 Zinc Plated Spring Washer 2
26 45045 M16 x 75 Class 8.8 Zinc Plated Bolt 1
To Next Page
