20
‘Enviro DD30’ Sowing Chart Normal
Box contents
Butterfl y Position (aff ects rear box) Fan Speed/rpm*
FRONT REAR
seed (Normal) seed (Normal) open - 5 3000
seed (Normal) seed (Fine) closed - 1 3000
Fertilizer seed (Normal) closed -2 3000 to 3500
Fertilizer seed (Fine) closed - 1 3000 to 3500
1
5
2
3
4
*MAXIMUM PERMISSABLE SPEED 4000 RPM
NORMAL SEED (toggle NORMAL, Butterfl y Valve Settings shown below and on page 22)
PRODUCT
SPECIFIC
GRAVITY (kg/l)
Setting
Position> *10* *15* *20* *25* 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110
RATE*
Wheat 0.8 high 34 51 69 86 104 122 140 157 174 192 210 228 246 264 281 298 316 335 352 370 387
Oats 0.5 high 24 35 47 59 71 82 94 106 118 130 141 153 165 177 189 200 212 224 236 248 260
Barley 0.7 high 32 48 64 79 95 111 127 143 159 174 190 206 222 238 253 268 284 300 316 332 348
Ryecorn 0.7 high 33 49 66 83 100 117 134 151 168 184 200 217 235 252 269 286 302 319 337 354 371
Peas 0.8 high 21 40 59 78 97 117 136 155 174 194 213 232 251 270 289 309 328 347 366 385 404
Grass 0.4 high 18 26 34 42 50
Pasture Mix - high 18 26 34 42 50
DAP 1.0 high 39 58 77 97 116 135 155 174 193 213 232 251 270 290 309 328 348 367 386 406 425
Superphosphate 1.3 high 34 70 109 138 171 204 235 266 303 336 366 390 421 451 489 524 558 586 622 660
INCREASED ACCURACY FOR SETTING POSITION<25mm (toggle NORMAL, Butterfl y Valve Settings shown below and on page 22)
PRODUCT
SPECIFIC
GRAVITY (kg/l)
Setting
Position> *10* *15* *20* *25* 30
RATE*
Wheat 0.8 low 17 25.5 34.5 43 52
Oats 0.5 low 12 17.5 23.5 29.5 35.5
Barley 0.7 low 16 24 32 39.5 47.5
Ryecorn 0.7 low 16.5 24.5 33 41.5 50
Peas 0.8 low 10.5 20 29.5 39 48.5
Grass 0.4 low - 9 13 17 21
Pasture Mix - low - 9 13 17 21
