Pt. No. 67394

Issue 1121

ITEM PART No. DESCRIPTION QTY

1 60801k Duncan Tine Spring Head -

2 64510 Pivot Bolt (Cone Seat) 1

3 64511 Pivot Nut (Cone Seat) 1

4 45143 M24 Nyloc Nut 1

5 64512 Spring Cap 1

6 64513 Compression Spring 1

7 45024 M12 x 55 Grade 8.8 Z/P Bolt 2

8 64514 Spring Bolt 1

9 64515 Spring Bar 1

10 45139 M12 Nyloc Nut 2

11 64516 Pivot Arm (20mm Disc Mount) 1

12 64517 Lower Clamp 1

13 45040 M16 x 50 Grade 8.8 Z/P Bolt 2

14 64518 Upper Clamp 1

15 45050 M16 x 120 Grade 8.8 Z/P Bolt 2

16 - Grease Nipple M8 x 1P 1

17 64536 Pivot Bush 2

18 44173 6X8mm Straight High Pressure (for remote greasing) 1

‘Enviro DD30’ Disc Assemblies

Duncan Enviro DD30 - Page 55
