55
Pt. No. 67394
Issue 1121
‘Enviro DD30’ Disc Assemblies
ITEM PART No. DESCRIPTION QTY
1 66403 Press Wheel Fixed Plate RH 1
2 43953 Nylon Washer 30 x 70 x 2 2
3 66402 Press Wheel Fixed Plate LH 1
4 45140 M16 Nyloc Nut 3
5 45020 M12 x 35 Grade 8.8 Z/P Bolt 1
6 45023 M12 x 50 Grade 8.8 Z/P Bolt 1
7 Refer Page 56 Disc Mount Sub Assy (Straight shown) 1
8 Refer Page 58 Disc Scraper Assembly 1
9 45152 M10 Light Flat Washer 3
10 45166 M10 Spring Washer Z/P 3
11 45001s M10 x 20 Grade 8.8 Z/P S/Screw 3
12 63084 Press Wheel Bearing Sleeve 1
13 43939 Bearing 6205 2
14 66407 Press Wheel Arm Welded Assy 1
15 45052 M16 x 140 Grade 8.8 Z/P Bolt 1
16 29267 15”x80mm Wedge P/Wheel Scraper 1
17 45235 M12 x 35 CSK Socket HD Screw 1
18 45139 M12 Nyloc Nut 1
19 45045 M16 x 75 Grade 8.8 Z/P Bolt 2
20 10283 Oil Seal 2
21 61022 Bearing Mount for 6305 2
22 11351 Bearing 6305 2
23 43573 Press Wheel 15”x80 Solid Wedge (Tyre and Rim) 1
24 61021 Bearing Spacer for 6305 1
25 60294 Spring 1
26 63134P Slide Bar Washer 1
27 66409 Slide Bar W/Assy 1
28 43587 15”X80mm Solid Wedge Tyre (Tyre only) -
To Next Page
