Duncan Enviro DD30 - Page 63

61
Pt. No. 67394
Issue 1121
‘Enviro DD30’ Disc Assemblies
ITEM PART No. DESCRIPTION QTY
1 74829 DD DIsc Seal Spacer (replaces 45154 & 63102) 2
2 43352 Vee Ring Seal V-40A 2
3 63101 Stepped Spacer 2
4 63071 Plain Disc Sub Assy (includes items 6,7,8,9,10,12,14,15,16,17,18) 1
5 63072 Scalloped Disc Sub-Assy (includes 6,7,8,9,11,12,13,15,16,17,18) 1
6 29241 Bearing and Seal Sleeve 2
7 43891 Vee Ring Seal V-45A 2
8 22077 Dust Cap (16mm Bore) 2
9 45042 M16 x 60 Grade 8.8 Z/P Bolt 1
10 63103* Disc Retaining Bolt L/H M16x55 1
11 45002s M10 x 25 Grade 8.8 Z/P Set Screw 12
12 60841 Scalloped Disc 6 Hole One Side 1
13 22002 380 x 4mm Plain Disc 6 Hole 1
14 22081 Seal face Ring 2
15 29244 Bearing Housing Spacer 3mm 2
16 43890 Triple Seal Special Bearing 2
17 29243 Bearing Housing 6 Hole TS 2
18 45138 M10 Nyloc Nut 12
19 45154 M16 Light Flat Washer 1
*Left Hand Thread
