71
Pt. No. 67394
Issue 1121
‘Enviro DD30’ Footboard & Ladder
ITEM PART No. DESCRIPTION QTY
1 60163 End Guard Rail W/Assy 1
2 61705 Side Guard Rail W/Assy 1
3 43757 Drop Lock 1
4 45138 M10 Nyloc Nut 1
5 61700 Footboard Assembly 1
6 60170 Footboard Step Bracket W/Assy 1
7 63221 Ladder W/Assy 3 Step 1
8 63220 Ladder Securing Bracket 1
9 45002s M10 X 25 Grade 8.8 Z/P S/Screw 2
10 45152 M10 Light Flat Washer Z/P 2
11 45138 M10 Nylock Nut 2
12 64122 Guard Rail Multi-Purpose Frame 1
13 45023 M12 x 50 Grade 8.8 Z/P Bolt 8
14 45139 M12 Nyloc Nut 8
15 45155 M20 Light Flat Washer Z/P 2
16 45062 M20 x 50 Grade 8.8 Z/P Bolt 2
17 45141 M20 Nyloc Nut 2
To Next Page
