73
Pt. No. 67394
Issue 1121
‘Enviro DD30’ Seed/Fert Box
ITEM PART No. DESCRIPTION QTY
1 44064 Air Distributor Head 24 Outlet 2
2 44059 Blanking Plug Seed Distr Head (1 per head) 2
3 72787 Radial Brace Tube Top Support 2
4 44071 Tube 2
5 64427 Mesh Frame W/Assy 1
6 63166P Outlet Half Moon Flange Pro• le 4
7 72786 Radial Wall Bracket 2
8 63167 Mesh Grid Filter Hopper Bottom 1
9 63182 Hopper Cover Support Rod 2
10 63168 11 Hole Tube Inset Panel W/Assy (1 per compartment) 2
11 63150 MS Hopper W/Assy 1
12 43373 Edgetrim Black (per metre) -
13 63173 Cover Holding Extrusion -
14 63170 12 Hole Tube Inset Panel W/Assy (1 per compartment) 2
15 63260P Hopper Gasket Support Pro• le 2
16 72789 Rh Radial Brace Short 1
17 72788 Lh Radial Brace Short 1
18 Refer Page 74 Metering Unit 2
19 45412sss M8 X 25 S/Screw St. Stl. -
20 45151ss M8 Light Flat Washer 304 S/S -
21 45137ss M8 Nylock Nut Grade 304 S/S -
22 44951sss M6 x 16 316 S/S S/Screw -
23 45402sss M6 X 20 Grade 304 Ss S/Screw -
24 45150SS M6 Light Flat Washer 304 S/S -
25 45136SS M6 Nylock Nut Grade 304 S/S -
26 43430 Plastic lashing Hooks (not shown) 11
27 63174 Ripstop Hopper Cover (not shown) 1
28 63251 Air Delivery Hose Long (not shown) 1
29 63252 Air Delivery Hose Short (not shown) 1
30 44167 32mm Nyla• ow Air Seeder Hose 40mtr
31 43691 38mm Nyla• ow Air Seeder Hose 71mtr
To Next Page
