Utopia Gazebo 2x2m MKII Installation Manual
Page 9 of 9
Finally, fix 4x'70x35x1700.C' in the positions
shown using 4x70mm screws per component.
Screw through '70x35x1700.C' and into the
purlins.
70x35x1700.C
70x35x1700.C
70x35x1700.C
70x35x1700.C
Once you have fixed the bottom row on shingles
(with the cut outs pointing towards the roof) you
can now fully cover the roof of your gazebo with
shingles.
All of the strips of shingles will now have the cut
outs pointing towards the ground.
Start by fixing the shingle strips directly on top of
the bottom rows that were fixed in the previous
step, until your gazebo resembles the diagram.
