DURABLE 5087 - Height and Bracket Adjustments; Maintenance, Service, and Disposal; Cleaning and Maintenance

EN

English
Height adjustment
▶siehe Abbildung16
– Loosen the adjusting screw (12).
– Slide the arm bracket (4) to the desired position on the table
column (5).
– Fix the monitor arm again using the adjusting screw (12).
Moving the brackets
▶siehe Abbildung17
– Loosen the adjusting screws (13).
– Place the monitor and the tablet in the desired position.
– Fix the position of brackets using the respective adjusting screw
(13).
Exchanging monitor
▶siehe Abbildung18
– Remove the cable clamps and monitor cable.
– Lift the monitor slightly to relieve the clamps.
– Press the clamps (16) of the VESA plate(1) together as shown
and lift the monitor out of the bracket(15).
– Release the VESA plate from the monitor and attach these as
described above to the new monitor.
Cleaning and maintenance
WARNING!
Risk of product damage!
Do not use any abrasive or sharp objects or aggressive
cleaning agents.
Do not use any solvents.
– In order to prevent the mobility from decreasing due to dust de-
posits, regular dust removal on the monitor bracket is recom-
mended.
– Wipe the product with a dry or slightly damp microfibre cloth.
