5
Basic assembly of your EFXTRA is now complete.
Please perform a final check on all screws, bolts and compoents
ensuring all are secure and firmly in place.
9. Install the spinner back plate on to the motor shaft ensuring the notches on the rear
of the back plate align with the shafts base. Secure your supplied prop of choice (the
black 7x6.5 for 4S, or the grey 8x6 for 3S) with the prop nut and then secure the spinner
as shown below using the M3 bolt (3x10mm) provided.
3x10mm
Note: Double check your prop is balanced before installing. An unbalanced prop can
cause excess vibration and a loss in efficiency.
