5
2. The Microphone should be mounted either on the sun visor directly
aboveandfacingthedriver,orontheheadlinerjustaboveandfacingthe
driver.
Diagram2
3.The visor microphone has a noise canceling feature and must be
mountedfacingthedriverasshowninthepictureabove.
4. To avoid visual or physical obstruction, route the microphone cable
down inside the door molding. Allow sufficient slack on the connector
endofthecabletoreachth
eJunctionBox.
5.Feedthecabletothelocationwhereyouintendtomountthejunction
box.
Note! The microphone should not be mounted near a window or in a
spot where road and ambient background noise would be substantially
high(above85dBSPL).
C.MountingofthePTT
1.ToattachthePTTtothegearlever,strapthePTTaroundthegearlever
usingtheVelcrostripattached,withthecordfacingdown.
Diagram3
Facin
