3
Standard Description Lithium Range Wet AGM EFB
CCA: Cold Cranking Amps, specied by SAE & BCI 20-1000 100-2000
BCI: Battery Council International standard 20-1000 100-2000
CA: Cranking Amps standard, effective starting current
value at 0°C
20-1000 100-2000
MCA: Marine Cranking Amps standard, effective starting
current value at 0°C.
20-1000 100-2000
JIS: Japan Industrial Standard 26A17-150F51 26A17-245H52
DIN: German Auto Industry Committee Standard 20-700 100-1400
IEC: Internal Electro technical Commission Standard 20-700 100-1400
EN: European Automobile Industry Association Standard 20-1000 100-2000
SAE: Society of Automotive Engineers Standard 20-1000 100-2000
GB: China National Standard 2-120 30-220
Health:96% 490CCA
Charge:98% 12.64V
Internal R=6.1mΩ
Rated: 500A
GOOD BATTERY
Health:78% 440CCA
Charge:30% 12.20V
Internal R=7.2mΩ
Rated: 500A
GOOD, RECHARGE
Health:46% 490CCA
Charge:80% 12.68V
Internal R=18.1mΩ
Rated: 500A
REPLACE
Health:39% 310CCA
Charge:20% 12.08V
Internal R=30.1mΩ
Rated: 500A
CHARGE - RETEST
Health:0% 0CCA
Charge:20% 10.64V
Internal R=45.2mΩ
Rated: 500A
BAD CELL REPLACE
Cranking Test
• Select CRANKING TEST: the tester then displays the following:
Cranking Test
Start Engine
Cranking Test
RPM Detected
Cranking Test
Time 780ms
Cranking Low
9.12V
Cranking Test
Time 780ms
Cranking Normal
10.13V
Replace
Good
• Press UP/DOWN key to select according to the actual system standard and rating
marked on the battery itself.
• Batteries are marked with a variety of specications, the tester works with:
• Press ENTER to start the test.
• The test can take several seconds to before the result is shown on screen:
