Dwg # Part # Part Description
7 61799-01 Cartridge Assembly with Piston
76 11335 Screw, 4-40X3/16
97 16394 O-Ring, 029
98 13287 O-Ring, 123
99 61799 Seal and Spacer Cartridge
100 42920 Piston
101 19984 Piston Rod
6200 Service Kits – Flow Meter (Optional)
Dwg # Part # Part Description
84 19791-01 Cable, Meter
22 19569 Clip, Flow Meter
24 13314 Screw, Slot Hex, 8-18 X0.6
23 19797 Meter, Assy,3 /4" Dual Port
105 13305 O-Ring, -119
21 14613 Flow Straightener
94 60626 Meter Only, Electronic Turbine
84
24
22
23
21
94
105
6200 Service Kits – Circuit Board
Dwg # Part # Part Description
82 19474-01 Harness, Power, SXT
84 19791-01 Cable Meter
36 42766-02 Circuit Board, SXT
37 17020 Screw
37
82
84
36
To Next Page
