Servicing and Replacing Drain Line Flow Control (DLFC)
1. Disconnect the drain line retainer clip.
2. Remove the DLFC assembly and pull the flow washer out
of the DLFC housing with the help of plier.
3. Remove the flow washer from the housing and clean it
with water to remove any debris. Replace it with a new
washer if necessary.
4. Re-install the DLFC housing and retainer.
DLFC
Retainer
Flow Washer
Housing
Hose
Barb
Flow Washer
