FUNCTIONAL DESCRIPTION
CONTROLS AND COMPONENTS:
1. 3/8” / 1/2” Square (Male) 2. LCD Panel
3. Power Button(C/S: Clear / Start) 4. Down Button
5. Up Button 6. 1/2” Square (Female)
LCD DISPLAY EXPOSITION:
RM602-3, RM602-4A
Modes:
1. S: Set Mode
2. P: Peak Mode
3. T: Trace Mode
RM604-4A
Modes:
1. S: Set Mode
2. P: Peak Mode
3. T: Trace Mode
4. A: Angle Mode
Measuring Units:
1. N-m: Newtown Meters
2. kg-cm: Kilogram Centimeters
3. ft-lb: Foot Pounds
4. in-lb: Inch Pounds
