Displacement 439cc
Fuel Type ≥87 octane, ≤10% ethanol, unleaded gasoline
Dry Weight 77 lbs
Maximum Torque 27 ft. lb @ 2500 RPM
Compression Ratio 8.5:1
Bore X Stroke 92 mm x 66 mm
Engine Oil Capacity 37.2 oz.
Fuel Tank Capacity 1.7 Gal.
Lowest Idling Speed 1800 RPM ± 300 RPM
Dimensions LENGTH 19.5 in.
WIDTH 17.5 in.
HEIGHT 19.3 in.
Engine Type 4-Stroke OHV Forced-Air
Ignition System Non-Contact Transistor
Lubrication Mode Splash
Starting Type Recoil
Shaft Rotation Counter-Clockwise
Shaft Size 1” Diameter, 2-3/4” Long, 1/4” Keyway
Shaft End 3/8” Size 24 UNF - Drilled and Tapped
Center of Shaft to Base 5”
Bearing Type Stainless steel ball bearing
Cylinder Sleeve Type Cast iron sleeve
Fuel Delivery System Carburetor
SPECIFICATIONS
43
