DUROMAX XP652WP - Page 32

32
Item
Part
Qty
Description
Item
Part
Qt
y
Description
91
DS30-32001-A
1
Casing
105
DS30-32003-A
1
Suction port
92
GB97.1-W-8
4
Gasket

8x1.6
106
DS30-32008-A
2
Coupling Packing
93
GB70-B8-60
4
Flange Bolt M8×60
107
DS30-32010-A
2
Hose Joint
94
DS30-32052-A
1
Casing Gasket
108
DS30-32200-A
2
Hose Coupling
95
DS30-32013-A
1
Mechanical seal A
109
DS30-32009-A
1
Discharge gasket
96
DS30-32013-B
1
Mechanical seal B
110
DS30-32004-A
1
Discharge port
97
DS30-32005-A
1
Impeller
111
DS30-32016-A
3
Hose Band
98
DS30-32006-A
1
Case Volute
112
DS30-32020-A
1
Strainer
99
DS30
-32011
-A
1
O
-Ring Seal 1
13
XP650WP
-
31100
-A
1
Frame
100
DS30
-32002
-A
1
Pump case housing
114
GB6177
-N8
4
Flange
nut M8
101
GB5787
-B8-
25
12
Flange
Bolt M8×25 1
15
GB578
7-B8-
35
4
Flange bolt M8×35
102
DS30-32050-A
2
O-ring, Plug
116
DS20-31203-A
4
Rubber pad, damping
103
DS30-32049-A
2
Plug
117
GB5787-B6-12
4
Flange Bolt M6×12
104
DS30-32030-A
1
Flapper valve gasket
