DUROMAX XP652WP - Page 36

36
58
11201
1
Head comp, cylinder
80
14406
1
Arrester, spark
59
14002
2
Bolt head, M8×34
81
14400
1
Muffler
60
18500
1
Plug, spark
82
14417
1
Muffler guard
61
13101
1
Camshaft assy.
83
GB847-85
5
Screw, tapping M5×8
62
13009
2
Lifter, valve
84
GB5789-86
7
Flange bolt M8×35
85
11006
1
Cap, oil hole
98
15008
1
Spring, throttle return
86
11001
1
Crankcase cover
99
15005
1
Bolt, governor arm
87
11003
1
Packing, case cover
100
15004
1
Arm, governor
88
11002
2
Pin, dowel, 8×12
101
14300
1
Fuel tank
89
11007
1
Cap assy. oil filler
102
GB5789-86
2
Flange bolt M8×25
90
15100
1
Governor kit
103
11013
1
Rubber, supporter
91
12003
2
Clip, piston pin
104
14008
1
Fuel cock
92
12002
1
Pin, piston
105
14007
1
Outlet pipeφ4.5×235
93
12300
1
Ping set assy. piston
106
14026
1
Joint, fuel tank
94
12001
1
Piston
107
14311
1
Rubber joint, fuel tank
95
12200
1
Connecting rod assy.
108
14307
1
Fuel filter
96
15200
1
Control assy.
109
14306
1
Fuel filler cap comp
97
15007
1
Spring, governor
