ITEM PART QTY DESCRIPTION ITEM PART QTY DESCRIPTION
109 DS40-32001 1 ASSEMBLY, PUMP COVER 123 DS40-32003 1 SUCTION PORT
110 DS40-32015 4 WASHER 124 DS40-32008 2 COUPLING PACKING
111 GB5787-86 4 FLANGE BOLT M8X45 125 DS40-32010 2 HOSE JOINT
112 DS40-32012 1 O-RING, WATER PUMP 126 DS40-32200 2 HOSE COUPLING
113 DS40-30258 1 MECHANICAL SEAL A 127 DS40-32009 1 DISCHARGE GASKET
114 DS40-32038 1 MECHANICAL SEAL B 128 DS40-32004 1 DISCHARGE PORT
115 DS40-32005 1 IMPELLER, WATER PUMP 129 DS40-32016 3 HOSE BAND
116 DS40-32006 1 VOLUTE CASING 130 DS40-32020 1 STRAINER
117 DS40-32011 1 RING, VOLUTE CASING 131 DS40-31100 1 FRAME
118 DS40-32002 1 PUMP CASE HOUSING 132 GB6177-86 4 FLANGE NUT M10
119 GB5787-86 12 FLANGE BOLT M10X25 133 GB5789-86 4 FLANGE BOLT M10X35
120 DS40-32050 2 O-RING, PLUG 134 DS40-31203 4 RUBBER PAD, DAMPING
121 DS40-32049 2 PLUG 135 GB5787-86 4 FLANGE BOLT M6X16
122 DS40-32030 1 FLAPPER VALVE GASKET
