Displacement 212 cc
Fuel Type ≥87 octane, ≤10% ethanol, unleaded gasoline, propane
Dry Weight 48 lbs
Maximum Torque 13.2 N·m @ 2500 rpm
Compression Ratio 9:1
Bore X Stroke 70 mm x 55 mm
Engine Oil Capacity 20.3 . oz (0.6 L)
Fuel Tank Capacity 0.76 gal. (2.885 L)
Lowest Idling Speed 1800 rpm ± 300 rpm
Dimensions LENGTH 16.14 in.
WIDTH 11.5 in.
HEIGHT 14.76 in.
Engine Type 4-Stroke OHV Forced-Air
Ignition System Non-contact transistor
Lubrication Mode Splash
Starting Type Electric / Recoil
Shaft Rotation Counter-clockwise
Shaft Size 3/4” diameter, 2-3/8” long, 3/16” key-way
Shaft End 5/16” size 24 UNF - drilled and tapped
Gasoline Consumption ≤395 g/kWh
Center of Shaft to Base 4.175”
Bearing Type Stainless steel ball bearing
Cylinder Sleeve Type Cast iron sleeve
Fuel Delivery System Carburetor
SPECIFICATIONS
53
