14
Figure 1
Take off plug
Figure 2
Plug drainage pipe with
14mm inner diameter in
the hose connector
Note: Gently stretch the drainage pipe if it is squashed or twisted, otherwise
drainage will be restricted and the unit will not work normally. During the
operation, drainage pipe should never be in a higher position than the hose
connector.
How To Use
1. ON/OFF: Press once to turn unit ON or OFF.
a. Press “ON/OFF” once and the unit will begin to work.
b. Press “ON/OFF” once again after use and the unit will shut down.
Note: Let the unit rest for about 3 minutes after turning off, so that residual
water on condenser can ow into the tank. Pull out the plug when the unit is
off for power saving and safety.
To Next Page
