Dux 3F136S - Installation Details; Location

Owner’s Manual – Electric Boosted Solar
2
Part No: H3100
Version: 10346D
Installation Details – Tank
Location
The water heater should be located as
close as possible to the most frequently
used hot water outlet. Ensure that the
data plate is clearly visible and provide
adequate access for service to the
thermostat, relief valve and anode.
Note: All models are equipped with a
sacricial anode, accessible through the
top cover. Allow 50% of the height of
the water heater for clearance above to
replace the anode.
This water heater must be installed
on a re-proof base.
The water heater has a metal base so it
is recommended that a concrete plinth
be installed under the water heater to
protect the heater when subjected to
wet conditions.
A properly drained overow tray must
be used where property damage could
occur from water spillage. (See AS/
NZS3500.4 for further details.)
Note: Warranty does not cover
consequential damage due to heater
leakage.
