Dwyer Instruments Digihelic DHC Series User Manual

[3] HOLES FOR #6 SCRE
W
EQUALLY SPACED ON
Ø4-1/8 [104.78] B.C.
1-1/2 [38.10]
3/4 [19.05]
7/8 [22.23]
1 [25.40]
53/64 [20.96]
1 [25.40]
2X Ø5/8 [15.88] FOR PRESSURE CONNECTION
DRILL TEMPLATE NEEDS TO
BE USED FROM PANEL FRONT
Figure 4: Surface mounting drill template
