You have purchased one of the following DX Engineering Universal Wire Antenna Kits:
DXE-UWA-KIT: EZ-BUILD
®
Center-T and End Insulators and hardware for wire and
ladder line antennas or for feedpoint-mounted DX Engineering Baluns.
10-24 x 3/4” Stainless Steel Carriage Bolt
#10 Stainless Steel Flat Washer
#10 Stainless Steel Split Washer
10-24 Stainless Steel Hex Nut
10-24 x 5/8 “ Stainless Steel Hex Head Bolt
DXE-UWA8X-KIT: EZ-BUILD
®
Center-T and End Insulators, Medium/Low Power
connector assembly with SO-239 for PL-259 feedline, plus coaxial cable strain relief bracket,
clamps and hardware. The DXE-UWA8X-KIT will handle low and medium power levels
and tolerate medium SWR levels.
DXE-UWA213-KIT: This is a special high power model of DX Engineering’s EZ-BUILD
®
versatile insulator kit for building a wire antenna of almost any design. It includes a
completely unique coaxial cable connector and feedline strain relief system. When using a
high power amplifier or high duty cycle modes of operation such as AM, RTTY or FM, this
kit should be used. It will handle higher power levels and tolerate higher SWR levels than
the DXE-UWA8X-KIT.
Cable Strain Relief Bracket
10-24 Stainless Steel Nyloc Nut
10-24 x 1” Hex Head Stainless Steel Bolt
10-24 x 5/8” Stainless Steel Carriage Bolt
UHF Female to Female Adapter, 1”
Cushioned Loop P-Clamp 1 Large, 1 Small
Pigtail with Ring Terminals installed
Plus all the parts listed in the DXE-UWA-KIT
* P-Clamp size is smaller for the 8X-KIT than the 213-KIT
** The pigtail for the DXE-UWA8X-KIT uses RG-8X coaxial cable
The pigtail for the DXE-UWA213-KIT uses RG-213 coaxial cable
Tools Required
3/8” Wrench, Pliers, 3/8” Socket and Drive or 3/8” Nut Driver, and Wire Stripper
11/32" Wrench and Phillips Head Screwdriver - Used for mounting a balun to the Center-T
